Edge Milling Machine Manufacturer
Devraj Engineering is an Edge Milling Machine Manufacturer offering machines used for preparing and finishing the edges of metal plates before welding and fabrication. The machine helps create clean and accurate bevels on plate edges, making the plates ready for welding. Since 1971, the company has manufactured and supplied industrial machinery for different engineering and fabrication requirements.
This machine is mainly used when proper edge preparation is needed before joining metal plates. It can help maintain a consistent bevel angle and smooth edge finish, which is useful in fabrication work where accurate welding is required.
Edge Milling Machine Supplier
Devraj Engineering supplies machines for industries involved in heavy fabrication and metal plate processing. The machine can be used for preparing plate edges in applications such as pressure vessel manufacturing, shipbuilding, structural steel fabrication and other heavy engineering work.
The machine page specifies adjustable bevel angles, a high-speed milling head and hydraulic clamping and feed arrangements. Custom-built models are also available based on the required application.
Features
Rigid steel structure for
stable operation
Adjustable bevel angle
from 0° to 45°
High-speed
milling head
Carbide milling
cutter options
Hydraulic
clamping system
Hydraulic or controlled
feed movement
Smooth and consistent
edge milling
Smooth and consistent
edge milling
Suitable for plate
edge preparation
Custom-built
machine options
Applications
Pressure vessel manufacturing
Shipbuilding
Offshore structure fabrication
Wind tower fabrication
Steel bridge construction
Structural steel fabrication
Heavy machinery manufacturing
Boiler manufacturing
Heat exchanger fabrication
Hydropower equipment manufacturing
Storage tank fabrication
Pipeline manufacturing
General fabrication work
| Parameter | Specification |
|---|---|
| Model | DEM-EM Series (Customizable) |
| Plate Thickness Capacity | 6 mm - 100 mm |
| Maximum Plate Width | Up to 3000 mm (Custom sizes available) |
| Bevel Angle Range | 0° to 45° (Adjustable) |
| Milling Head Motor Power | 7.5 kW - 15 kW (Based on model) |
| Feed Type | Manual / Hydraulic / Servo-controlled |
| Feed Speed | 100 mm/min - 1000 mm/min (Adjustable) |
| Milling Cutter Type | Carbide-tipped or Insert-type Cutter |
| Surface Finish | ≤ Ra 3.2 µm |
| Clamping System | Hydraulic / Mechanical |
| Control System | Manual, Semi-Automatic, or CNC |
| Machine Bed | Heavy-duty fabricated steel structure |
| Power Supply | 415 V ±10%, 50 Hz, 3 Phase |
| Operation Mode | Continuous duty, high precision |
| Optional Accessories | Dust extraction system, coolant system, extended bed length, automation kit |
FAQs
1. What is an Edge Milling Machine used for?
An Edge Milling Machine is used to prepare the edges of metal plates before welding. It removes material from the plate edge to create the required bevel and a smoother surface.
2. What bevel angle can an Edge Milling Machine provide?
The machine listed by Devraj Engineering has an adjustable bevel angle range of 0° to 45°. The required angle can be set according to the plate and welding requirements.
3. What industries use Edge Milling Machines?
This machine is used in industries such as pressure vessel manufacturing, shipbuilding, structural steel fabrication, wind tower fabrication, boiler production, pipeline manufacturing and heavy machinery manufacturing.
4. What type of plates can be processed using an Edge Milling Machine?
The machine is used for preparing metal plates for welding and fabrication. The suitable plate thickness and size depend on the machine model and its capacity.
5. Are the Edge Milling Machine be customized?
Yes, Company’s Edge Milling Machine range includes custom-built models. The machine can be selected or configured according to the required plate size, bevel angle and application.
